2001 Techno Coating Engineering

TECHNO COATING ENGINEERING CAST FILM EXTRUSION LINE

Number of layers: 3

Film structure: ABC

Material: stretch film LLDPE

Film width: 2000mm

Output: 950kg/h

Extruder 1 layer: A

Screw diameter 1: 100mm

Description 1: DC motor 106kw

Extruder 2 layer: B

Screw diameter 2: 160mm

Description 2: ac motor ABB 320kw

Extruder 3 layer: C

Screw diameter 3: 130mm

Description 3: ac motor ABB 220kw

Head: automatic Cloeren 2450mm total width

Die width: 2450mm

Chill roll unit: diameter 1000mm

Thickness control: electronic systems 2 Beta sensors

Rewind maximum reel diameter: 420mm

Rewind: jumbo reels, automatic

Exact regranulating recycling unto for trims
